SCPI Command Reference
Operating Manual 1145.1084.12 – 30 698
Parameter
Circuit model
Capacitances
Resistances
Inductances
SLCS
Shunt L, serial Cs
C1, C2
R1, R2, R3
L1
SCLS
Shunt C, serial Ls
C1
R1, R2, R3
L1, L2
SCCS
Shunt C, serial Cs
C1, C2, C3
R1, R2, R3
–
SLLS
Shunt L, serial Ls
–
R1, R2, R3
L1, L2, L3
Circuit models for single ended port embedding/deembedding:
Parameter
Circuit model
Capacitances
Resistances
Inductances
FIMPort
File import, no circuit model
–
–
–
CSL
Serial C, shunt L
C1
R1, R2
L1
LSC
Serial L, shunt C
C1
R1, R2
L1
CSC
Serial C, shunt C
C1, C2
R1, R2
–
LSL
Serial L, shunt L
–
R1, R2
L1, L2
SLC
Shunt L, serial C
C1
R1, R2
L1
SCL
Shunt C, serial L
C1
R1, R2
L1
SCC
Shunt C, serial C
C1, C2
R1, R2
–
SLL
Shunt L, serial L
–
R1, R2
L1, L2
Circuit models for ground loop embedding/deembedding:
Parameter
Circuit model
Capacitances
Resistances
Inductances
FIMPort
File import, no circuit model
–
–
–
SL
Shunt L
–
R
L
SC
Shunt C
C
R
–
CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<Log_pt>:PAR
ameters:C<no> STSC | SCST | CSSL | LSSC | CSSC | SLCS | SCLS |
SCCS,<numeric_value>
Specifies the capacitance values C1, C2, C3 in the different circuit models for balanced port
deembedding.
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
<Log_pt>
Logical port number (balanced port)
<no>
Number of capacitance in circuit model. If unspecified the numeric suffix is set
to 1.
Range [def. unit]
1 to 3 [–] The number of capacitances depends on the selected circuit model.
Parameters
Possible circuit models (character data); see circuit models.
*RST value
– (see command type description below)
