ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 697
SCPI, Command Types
Confirmed (with some device-specific parameters), command or query
Example:
See CALCulate<Chn>:TRANsform:TIME:DCHebychev
CALCulate<Chn>:TRANsform:TIME:XAXis TIME | DISTance
Switches over between the x-axis scaling in time units or distance units.
<Chn>
Channel number used to identify the active trace
TIME
x-axis scaled in time units
DISTance
x-axis scaled in distance units (Distance = Time * c
0
* Velocity Factor)
*RST value
OFF [–]
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; :CALC:TRAN:TIME:STAT ON
Reset the instrument, activating a frequency sweep, and enable the time
domain transformation for the default trace.
CALC:TRAN:TIME:XAX DIST
Convert the x-axis scaling to distance units.
CALCulate<Ch>:TRANsform:VNETworks...
This subsystem defines the circuit models for single ended and balanced port (de-)embedding and
activates the (de-)embedding function.
The circuit models are referenced by means of predefined character data parameters. They are different
for single ended port, balanced port, and ground loop (de-)embedding.
Circuit models for balanced port and port pair embedding/deembedding:
Parameter
Circuit model
Capacitances
Resistances
Inductances
FIMPort
File import, no circuit model
–
–
–
STSL
Serial Touchstone (.s2p) data, shunt L
–
R1
L1
STSC
Serial Touchstone (.s2p) data, shunt C
C1
R1
–
SLST
Shunt L, serial Touchstone (.s2p) data
–
R1
L1
SCST
Shunt C, serial Touchstone (.s2p) data
C1
R1
–
CSSL
Serial Cs, shunt L
C1, C2
R1, R2, R3
L1
LSSC
Serial Ls, shunt C
C1
R1, R2, R3
L1, L2
CSSC
Serial Cs, shunt C
C1, C2, C3
R1, R2, R3
–
LSSL
Serial Ls, shunt L
–
R1, R2, R3
L1, L2, L3
