R&S ZVB - Page 706

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 691
SCPI, Command Types
Device-specific, command or query.
Example:
See [SENSe<Ch>:]PORt<phys_port>:ZREFerence
CALCulate<Chn>:TRANsform:TIME:CENTer <numeric_value>
Defines the center time of the diagram in time domain.
<Chn>
Channel number used to identify the active trace
<numeric_value>
Center time of the diagram in time domain
Range [def. unit]
-99.99999999999 s to +99.99999999999 s. The increment (parameters UP
or DOWN) is 0.1 ns. [s]
*RST value
1.5E-009 s
SCPI, Command
Types
Confirmed, command or query
Example:
*RST; :CALC:TRAN:TIME:STAT ON
Reset the instrument, activating a frequency sweep, and enable the time
domain transformation for the default trace.
CALC:TRAN:TIME:CENT 0; SPAN 5ns
Set the center time to 0 ns and the time span to 5 ns.
Note: If the x-axis is scaled in distance units (CALCulate<Chn>:TRANsform:TIME:XAXis
DISTance), then the center value is entered in m; the range and default value changes accordingly.
CALCulate<Chn>:TRANsform:TIME:DCHebyshev <numeric_value>
Sets the sideband suppression for the Dolph-Chebyshev window. The command is only available if a
Dolph-Chebyshev window is active (CALCulate<Chn>:TRANsform:TIME:WINDow DCHebyshev).
<Chn>
Channel number used to identify the active trace
<numeric_value>
Sideband suppression
Range [def. unit]
10 dB to 120 dB. The increment (parameters UP or DOWN) is 10 dB. [dB]
*RST value
32 dB
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; :CALC:TRAN:TIME:WIND DCH
Reset the instrument and select a Dolph-Chebyshev window for filtering the
data in the frequency domain.
CALC:TRAN:TIME:DCH 25
Set the sideband suppression to 25 dB.
CALCulate<Chn>:TRANsform:TIME:LPASs KFSTop | KDFRequency |
