R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 919
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Chn>:]PAE:C
[SENSe<Ch>:]PMMO
This subsystem controls the sensitivity correction of the external power meter which is used for a source
power calibration.
[SENSe<Ch>:]PMMO <boolean>
Selects the origin of the frequency information for the connected power meter.
<Ch>
Calibrated channel number
<boolean>
ON – from power meter entry in Port Configuration dialog
OFF – from source to be calibrated
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; SENS1:PMMO?
Query the default frequency origin for the power meter in channel 1. The
response is 0.
[SENSe<Ch>:]PORT...
This subsystem controls the frequency reference oscillator.
[SENSe<Ch>:]PORT<phys_port>:ZREFerence <real>[, <imaginary>]
Specifies the complex reference impedance for the physical port numbered <phys_port>.
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
<phys_port>
Physical port number. The number of ports depends on the analyzer model.
<real>
<imaginary>
Real and imaginary part of the port impedance. <imaginary> may be omitted
to define a real impedance.
Range [def. unit]
1mΩ to 10 MΩ for the real part [Ω]
–10 MΩ to 10 MΩ for the imaginary part [Ω]
*RST value
Default reference impedance of the connector family assigned to the port
(real impedance, e.g. 50 Ω).
SCPI, Command
Types
Device-specific, command or query
