R&S ZVB - Page 753

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 738
<Element>
Display Element
1
Background
2
Text
3
Selected Text
4
Grid
5
Reference Line
6
Same Color for all Markers
7
Horizontal Line / Vertical Range Lines
8
Diagram Title
9
Limit Fail Trace Color
10
Limit Line Type Off
11
Limit Line Type Upper
12
Limit Line Type Lower
13
Trace 1 (see also DISPlay:CMAP<Element>:TRACe:RGB)
14
Trace 2
15
Trace 3
16
Trace 4
17
Trace 5
18
Trace 6
19
Trace 7
20
Trace 8
21
Trace 9
22
Trace 10
23
Trace 11
24
Trace 12
25
Trace 13
26
Trace 14
27
Trace 15
28
Trace 16
DISPlay:CMAP<Element>:TRACe:COLor[:STATe] <Boolean>
Defines the trace color schemes in different diagram areas.
<Element>
Numeric suffix, not used in this command. Implemented for compatibility with
DISPlay:CMAP<Element>:RGB.
<Boolean>
OFF – Independent color scheme in new diagram area. Moved traces change
their color.
ON – Color scheme in new diagram area continues the previous color scheme.
Moved traces keep their color.
