*RST value
*RST does not affect the color settings; see also description of the Preset
command.
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; :DISP:CMAP13:RGB 1,0,0
Create diagram area no. 1 (with default trace showing the S-parameter S
21
) and
color the trace red.
DISP:CMAP:TRAC:COL OFF; :DISP:WIND2:STAT ON
Select independent color schemes for new diagram areas. Create a new
diagram area no. 2.
CALC:PAR:SDEF 'TRC2', 'S11'; :DISP:WIND2:TRAC2:FEED 'TRC2'
Create a new trace named TRC2 and display the trace in a new diagram area
no. 2. The new trace is red like the first trace.
DISP:CMAP:TRAC:COL ON; :DISP:WIND3:STAT ON
Continue the same color scheme in new diagram areas. Create a new diagram
area no. 3.
CALC:PAR:SDEF 'TRC3', 'S22'; :DISP:WIND3:TRAC3:FEED 'TRC3'
Create a new trace named TRC3 and display the trace in a new diagram area
no. 3. The new trace is not red.
DISPlay:CMAP<Element>:TRACe:RGB '<trace_name>, <red>, <green>, <blue>
[,<trace_style>, <trace_width>]
Defines the color of a trace referenced by its name, based on the Red/Green/Blue color model. Use the
generalized command DISPlay:CMAP<Element>:RGB to define the color of other display elements.
<Element>
Numeric suffix, not used in this command. Implemented for compatibility with
DISPlay:CMAP<Element>:RGB.
'<trace_name>'
Trace name, string parameter
<red>
<green>
<blue>
Red, green, and blue content of the defined color.
Range [def. unit]
0 (zero intensity, corresponding to a 0 in the 24-bit color model) to 1 (full
intensity, corresponding to 255 in the 24-bit color model) [–]
<trace_style>
Optional trace style, only for traces (<Element> > 12): One of the string
parameters SOLid | DASHed | DOTTed | DDOTted | DDDotted.
<trace_width>
Optional trace width, only for traces (<Element> > 12).
Range [def. unit]
1 to 20 [–]
*RST values
*RST does not affect the color settings; see also description of the Preset
command.
SCPI, Command
Types
Device-specific, command or query. The query returns three values between 0
and one, separated by commas, corresponding to the red, green, and blue color
content.
Example:
*RST; :DISP:CMAP:TRAC:RGB 'Trc1', 1, 0, 0
