R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 740
Color the default trace 'Trc1' red..
See also DISPlay:CMAP<Element>:RGB
DISPlay:MENU:KEY:EXECute '<menu_key>'
Executes the function of a key with a specified name and switches to the local screen.
You can use this command to execute part of your measurement task manually; see Combining
Manual and Remote Control. Menu keys that initiate events are executed immediately, because no
additional input is necessary. However, DISPlay:MENU:KEY:EXECute can be used as well for manual
entries in numeric entry bars, dialogs or wizards.
Name of the key as shown in the analyzer's softkey bar (case-sensitive string
variable, may contain blanks but no dots). If the name is not unique, the complete
menu path, preceded by a colon, can be specified, e.g.
':Trace:Format:Phase'. Menus, submenus and menu function must also be
separated by colons.
If the name designates a menu entry that opens a sub menu, the respective sub
menu is activated. (Note: It is not possible to activate a menu that contains only
sub menu entries. For example, ':DISPlay:MENU:KEY:SELect :Trace' will
fail.)
Device-specific, no query
*RST; :DISP:MENU:KEY:EXEC 'S11'; EXEC ':Trace:Format:Phase'
Assign the S-parameter S
11
to the default trace, open the local analyzer screen,
then display the phase of the measured quantity. The commands are executed
immediately without any manual entry.
DISP:MENU:KEY:EXEC 'Start'
Open the numeric input bar for the start frequency of the sweep. The frequency
can be entered manually.
DISP:MENU:KEY:EXEC 'About Nwa'
Display information about your network analyzer and the firmware version. The
info box is closed when you click the analyzer screen or if you send another
command.
DISPlay:MENU:KEY:SELect '<menu_key>'
Activates the menu or submenu of the specified key.
Name of the key as shown in the analyzer's softkey bar (case-sensitive
string variable).
