ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 741
SCPI, Command
Types
Device-specific, no query
Example:
*RST; :DISP:MENU:KEY:SEL 'S11'
Open the Trace – Meas menu in order to select a measured quantity.
DISPlay:RFSize <rel. size>
Defines the size of the fonts in the diagram on a relative scale.
<rel size>
Relative font size
Range [def. unit]
80 % to 170 % [%]
*RST value
100 %
SCPI, Command Types
Device-specific, with query
Example:
*RST; :DISP:RFS 80
Use smaller fonts to gain more space for the traces in the diagram.
DISPlay[:WINDow<Wnd>]:CATalog?
Returns the numbers and names of all diagram areas in the current setup.
<Wnd>
Number of a diagram area. This suffix is ignored; the command returns a list of all
diagram areas.
Response
String with comma-separated list of diagram area numbers and names, see
example below. If all diagram areas have been deleted the response is an empty
string ("").
*RST value
–
SCPI,
Command
Types
Device-specific, query only.
Example:
*RST; :DISP:WIND2:STAT ON
Create diagram area no. 2.
DISP:WIND2:NAME 'S11 Test Diagram'
Assign a name to the new diagram area.
DISP:CAT?
Query all diagram areas and their names. As a default diagram area no. 1 is
created upon *RST, the response is ''1,1,2,S11 Test Diagram'. The first
diagram area is not named; its default name is equal to the diagram number.
CALC:PAR:SDEF 'Win2_Tr1', 'S11'
Create a trace named Win2_Tr1 to measure the input reflection coefficient S11.
DISP:WIND2:TRAC9:FEED 'Win2_Tr1'
