SCPI Command Reference
Operating Manual 1145.1084.12 – 30 742
Display the generated trace in diagram area no. 2, assigning the trace number 9 to
it.
DISP:WIND2:TRAC:CAT?
Query all traces in diagram area no. 2. The response is '9,Win2_Tr1'.
DISPlay[:WINDow<Wnd>]:MAXimize <Boolean>
Maximizes all diagram areas in the active setup or restores the previous display configuration.
<Wnd>
Number of the diagram area to become the active diagram area.
DISPlay:WINDow<Wnd>:MAXimize acts on all diagrams of the current setup,
however, the diagram no. <Wnd> is displayed on top of the others.
<Boolean>
ON | OFF - Maximize all diagram areas or restore the previous display
configuration.
*RST value
OFF
SCPI,
Command
Types
Device-specific, command or query (returns whether or not the diagrams are
maximized).
Example:
*RST; :DISP:WIND2:STAT ON
Create diagram areas no. 1 (with default trace) and 2 (with no trace).
DISP:WIND2:MAXimize ON
Maximize the diagram areas, placing area no. 2 on top.
DISPlay[:WINDow<Wnd>]:NAME '<string>'
Defines a name for diagram area <Wnd>. The name appears in the list of diagram areas, to be queried by
DISPlay[:WINDow<Wnd>]:CATalog?.
<Wnd>
Number of the diagram area.
'<string>'
String variable for the name.
*RST value
''
SCPI, Command Types
Device-specific, command or query
Example:
See DISPlay[:WINDow<Wnd>]:CATalog?
DISPlay[:WINDow<Wnd>]:STATe <Boolean>
Creates or deletes a diagram area, identified by its area number <Wnd>.
<Wnd>
Number of the diagram area to be created or deleted.
