<Boolean>
ON | OFF - Creates or deletes diagram area no. <Wnd>.
*RST value
–
SCPI, Command
Types
Device-specific, command or query (returns whether or not a particular
diagram area exists).
Example:
CALC4:PAR:SDEF 'Ch4Tr1', 'S11'
Create channel 4 and a trace named Ch4Tr1 to measure the input reflection
coefficient S11.
DISP:WIND2:STAT ON
Create diagram area no. 2.
DISP:WIND2:TRAC9:FEED 'CH4TR1'
Display the generated trace in diagram area no. 2, assigning the trace
number 9 to it.
DISPlay[:WINDow<Wnd>]:TITLe:DATA '<string>'
Defines a title for diagram area <Wnd>.
<Wnd>
Number of the diagram area.
'<string>'
String variable for the title. The length of the title is practically unlimited but
should be kept short enough to be displayed in the diagrams.
*RST value
''
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; :DISP:WIND:TITL:DATA 'S21 Test Diagram'
Define a title for the default diagram area. The title is displayed below the top of
the diagram area.
DISP:WIND:TITL OFF; TITL:DATA?
Hide the title. The title is no longer displayed but still defined so it can be
displayed again.
DISPlay[:WINDow<Wnd>]:TITLe[:STATe] <Boolean>
Displays or hides the title for area number <Wnd>, defined by means of
DISPlay:WINDow<Wnd>:TITLe:DATA.
<Wnd>
Number of the diagram area.
<Boolean>
ON | OFF - Displays or hides the title.
*RST value
ON
SCPI, Command Types
Device-specific, command or query
Example:
See DISPlay:WINDow<Wnd>:TITLe:DATA.
