ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 746
Types
Example:
CALC4:PAR:SDEF 'Ch4Tr1', 'S11'
Create channel 4 and a trace named Ch4Tr1 to measure the input reflection
coefficient S11.
DISP:WIND2:STAT ON
Create diagram area no. 2.
DISP:WIND2:TRAC9:FEED 'CH4TR1'
Display the generated trace in diagram area no. 2, assigning the trace
number 9 to it.
DISPlay[:WINDow<Wnd>]:TRACe<WndTr>:SHOW DALL | MALL | '<trace_name>',
<Boolean>
Displays or hides an existing trace, identified by its trace name (CALCulate<Ch>:PARameter:SDEFine
<Trace_Name>), or a group of traces.
You can open the trace manager (DISPlay:MENU:KEY:EXECute 'Trace Manager') to obtain an
overview of all channels and traces, including the traces that are not displayed.
<Wnd>
Number of a diagram area. This suffix is ignored; the command affects traces
in all diagram areas.
<WndTr>
Trace number. This suffix is ignored; the trace is referenced by its name.
DALL
MALL
'<trace_name>'
All data traces
All memory traces
Single trace identified by its trace name (string parameter), e.g. 'Trc4'.
*RST value
–
<Boolean>
ON | OFF – display or hide trace(s)
*RST value
1 (for the default trace 'Trc1')
SCPI, Command
Types
Device-specific, command or query. The query must be sent with the first
parameter; see example below.
Example:
*RST; :DISP:TRAC:SHOW? 'Trc1'
Reset the analyzer, creating the default trace 'Trc1'. The trace is displayed;
the query returns 1.
CALC4:PAR:SDEF 'Ch4Tr1', 'S11'
Create channel 4 and a trace named Ch4Tr1 to measure the input reflection
coefficient S
11
.
DISP:WIND2:STAT ON; :DISP:WIND2:TRAC:FEED 'CH4TR1'
Create diagram area no. 2 and display the generated trace in the diagram
area.
DISP:TRAC:SHOW DALL, OFF
Hide both traces in both diagrams.
DISP:TRAC:SHOW? DALL
