R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 750
parameter displayed in a dB Mag diagram is 10 dB.
Optional string parameter for the trace name, e.g. 'Trc4'. If this optional
parameter is present, both numeric suffixes are ignored (trace names must be
unique across different channels and windows).
CALC4:PAR:SDEF 'Ch4Tr1', 'S11'
Create channel 4 and a trace named Ch4Tr1 to measure the input reflection
coefficient S11.
DISP:WIND2:STAT ON
Create diagram area no. 2.
DISP:WIND2:TRAC9:FEED 'CH4TR1'
Display the generated trace in diagram area no. 2, assigning the trace number
9 to it.
DISP:WIND2:TRAC9:Y:PDIV 5
or: DISP:WIND2:TRAC:Y:PDIV 5, 'CH4TR1'
Set the value per division to 5 dB.
DISPlay[:WINDow<Wnd>]:TRACe<WndTr>:Y[:SCALe]:RLEVel <numeric_value>[,
'<trace_name>']
Sets the reference level (or reference value) for a particular displayed trace. Setting a new reference level
does not affect the value of PDIVision. The trace can be referenced either by its number <WndTr> or by
its name <trace_name>.
Number of an existing diagram area (defined by means of
DISPlay:WINDow<Wnd>:STATe ON). This suffix is ignored if the optional
<trace_name> parameter is used.
Existing trace number, assigned by means of
DISPlay:WINDow<Wnd>:TRACe<WndTr>:FEED. This suffix is ignored if the
optional <trace_name> parameter is used.
Value and unit for the reference level (or reference value, if the trace does not
show a level).
Range and unit depend on the measured quantity, see Units for DISPlay...
Commands.
Depending on the measured quantity. The default reference level for an S-
parameter displayed in a dB Mag diagram is 0 dB.
Optional string parameter for the trace name, e.g. 'Trc4'. If this optional
parameter is present, both numeric suffixes are ignored (trace names must be
unique across different channels and windows).
