power and time sweeps are Hz, dB and s, respectively.]
*RST value
0
<y_offset>
Response offset for limit lines loaded from a Touchstone file. A 1 dB offset shifts
the limit line by 1 dB in (positive) vertical direction.
Range [def. unit]
Depending on the measured quantity. [dB]
*RST value
0
<type>
Limit line type :
LMAX – upper limit line
LMIN – lower limit line
OFF – limit line off
*RST value
LMAX (if all optional parameters are omitted)
SCPI, Command
Types
Device-specific, no query.
Example:
Assume that the current setup contains two traces named
Trc1 and Trc2, respectively, and that limit lines have been
defined for Trc1.
MMEM:STOR:LIM 'TRC1', 'C:\Program
Files\Rohde&Schwarz\Network
Analyzer\LIMitLines\Lim_Trc1.limit'
Store the limit line definition of Trc1 to a limit line
file.
MMEM:LOAD:LIM 'TRC2', 'C:\Program
Files\Rohde&Schwarz\Network
Analyzer\LIMitLines\Lim_Trc1.limit'
Load the previously created limit line file and assign the
limit lines to Trc2.
MMEM:STOR:TRAC 'TRC1', 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\LIMitLines\Trc1.s1p'
Store the current trace data of Trc1 to a limit line file
in Touchstone format.
MMEM:LOAD:LIM 'TRC1', 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\LIMitLines\Trc1.s1p',
'S11', 0, 2, LMAX
Load the previously created Touchstone limit line file and
assign the limit lines to Trc1, applying a response offset
of 2 dB.
CALC:LIMit:DISPlay ON
Show the limit line in the diagram.
MMEMory:LOAD:MDAData <Channel>, '<file_name>' | CDELay
Loads the known delay values of a calibration mixer, to be used as a reference for a mixer delay
measurement calibration, and enables variable or constant delay mode. Mixer delay measurements are
