ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 777
controlled using the SENSe<Ch>:FREQuency:MDELay... commands.
<Channel>
Channel number
*RST value
–
'<file_name>'
String parameter to specify the name and directory of the loaded file. The default
extension (manual control) for files containing known delays is *.csv, although other
extensions are allowed. If no path is specified the analyzer searches the current
directory, to be queried with MMEMory:CDIRectory?. If a file name is specified,
the analyzer activates variable delay mode.
CDELay
Use the constant delay values defined via
SENSE<Ch>:FREQuency:MDELay:CDELay
*RST value
–
SCPI,
Command
Types
Device-specific, no query.
Example:
See MMEMory:LOAD:MDCData
MMEMory:LOAD:MDCData <Channel>, '<file_name>'
Loads correction data for a mixer delay measurement calibration from a specified file and assigns it to a
channel with a specified number. Mixer delay measurements are controlled using the
SENSe<Ch>:FREQuency:MDELay... commands.
Use MMEMory:LOAD:MDAData to load delay values of a calibration mixer stored in a file.
<Channel>
Channel number
*RST value
–
'<file_name>'
String parameter to specify the name and directory of the calibration file to be
loaded. The default extension (manual control) for mixer delay calibration files is
*.mcal, although other extensions are allowed. If no path is specified the analyzer
searches the current directory, to be queried with MMEMory:CDIRectory?.
*RST value
–
SCPI,
Command
Types
Device-specific, no query.
Example:
Assume that a mixer delay measurement has been configured and
enabled (see examples for the SENSe<Ch>:FREQuency:MDELay...
commands), and that a calibration mixer is connected to the
analyzer.
MMEM:LOAD:MDAD 1, 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\Calibration\MixerDelay\MDelay.csv'
Load mixer data for the calibration mixer and activate
variable delay mode.
SENS1:FREQ:MDELay:DIV ON
Divide the loaded calibration data by two.
