ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 778
SENS1:FREQ:MDELay:CORR OFF
Disable the current correction (if a correction is on).
SENS1:FREQ:MDEL:ACQ
Take a calibration sweep.
MMEM:STOR:MDCD 1, 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\Calibration\MixerDelay\Mixer1.mcal'
Store the measured calibration data for the calibration mixer
to a file.
For a new mixer delay measurement:
MMEM:LOAD:MDCD 1, 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\Calibration\MixerDelay\Mixer1.mcal'
Load the previously generated mixer delay calibration file
and apply the calibration data to the current mixer delay
measurement.
MMEMory:LOAD:PTRain <Channel>, <Generator>, '<file_name>'
Loads a pulse train definition from a specified file and assigns it to a channel with a specified number.
Pulse train definitions are created using the SENSe<Ch>:PULSe:GENerator<Gen>... commands.
<Channel>
Channel number
*RST value
–
<Generator>
Generator number. In the present firmware version, this number is always 1.
*RST value
1
'<file_name>'
String parameter to specify the name and directory of the pulse train file to be
loaded. The default extension (manual control) for pulse train files is *.train,
although other extensions are allowed. If no path is specified the analyzer searches
the current directory, to be queried with MMEMory:CDIRectory?.
*RST value
–
SCPI,
Command
Types
Device-specific, no query.
Example:
Assume that the current setup contains two channels Ch1 and
Ch2, and that a pulse train has been defined for Ch1.
MMEM:STOR:PTR 1, 1, 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\PulseTrain\PulseTrain.train'
Store the pulse train definition of Ch1 to a pulse train
file.
MMEM:LOAD:PTR 2, 1, 'C:\Program Files\Rohde&Schwarz\Network
Analyzer\PulseTrain\PulseTrain.train'
Load the previously created pulse train file and assign the
definition to Trc2.
