file.
MMEM:LOAD:TRAC 'TRC1', 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\Traces\Trc1.s2p'
Load the previously created Touchstone file and overwrite the
previously generated memory trace assigned to Trc1 with the
S
11
trace.
MMEMory:LOAD:VNETworks<Ch>:BALanced:DEEMbedding<Log_pt>
'<file_name>', PMAin | PSECondary[, IPORts]
Loads data from a specified Touchstone file defining a balanced port circuit model for deembedding.
Select a balanced port circuit model involving file import before using the command.
<Ch>
Channel number
<Log_pt>
Logical port number
'<file_name>'
String parameter to specify the name and directory of the loaded Touchstone file.
The balanced port circuit models STSL | STSC | SLST | SCST require two 2-
port (*.s2p) files, to be assigned to the different ports PMAin and PSECondary; the
FIMPort model requires a single 4-port (*.s4p) file but no additional port
assignment.
If no path is specified the analyzer searches the current directory, to be queried
with MMEMory:CDIRectory?.
Parameters
Port assignment for two 2-port (*.s2p) files:
PMAin – Port 1
PSECondary – Port 2
The ports must be specified for the import of 2-port (*.s2p) files; they must be
omitted for 4-port (*.s4p) files.
[IPORts]
Interchange port numbers of loaded *.s2p file. If the parameter is omitted, the port
numbers are not interchanged. The parameter must not be used for 4-port files.
*RST value
–
SCPI,
Command
Types
Device-specific, no query.
Example:
*RST; SOUR:LPOR1 1,2; LPOR2 3,4
Define a balanced port configuration.
CALC:TRAN:VNET:BAL:DEEM:TND STSL
Select the Serial .s2p data, shunt L circuit model.
MMEM:LOAD:VNET:BAL:DEEM2 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\VNET\Test.s2p', PMA
Load a Touchstone file and assign it to logical port no. 2.
