R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 787
MMEMory:LOAD:VNETworks<Ch>:SENDed:EMBedding<Ph_pt> '<file_name>'[,
IPORts]
Loads data from a specified two-port (*.s2p) Touchstone file defining a single ended circuit model for
embedding. Select the single end. Select the single ended port circuit model involving file import
(FIMPort)before using the command.
<Ch>
Channel number.
<Ph_pt>
Physical port number
'<file_name>'
String parameter to specify the name and directory of the loaded Touchstone file.
If no path is specified the analyzer searches the current directory, to be queried
with MMEMory:CDIRectory?.
*RST value
–
[IPORts]
Interchange port numbers of loaded *.s2p file. If the parameter is omitted, the port
numbers are not interchanged.
SCPI,
Command
Types
Device-specific, no query.
Example:
CALC:TRAN:VNET:SEND:EMB:TND FIMP
Select the Serial .s2p data circuit model.
MMEM:LOAD:VNET:SEND:EMB2 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\VNET\Test.s2p'
Load a Touchstone file and assign it to the physical port
no. 2.
MMEMory:MDIRectory '<directory_name>'
Creates a new subdirectory for mass memory storage in an existing directory.
'<directory_name>'
String parameter to specify the new directory. Either the full path or a
subdirectory for the current directory (see MMEMory:CDIRectory).
*RST value
–
SCPI, Command
Types
Device-specific, no query.
Example:
MMEM:MDIR 'C:\Documents and Settings\New_Directory'
Create the specified directory. The parent directory
'C:\Documents and Settings' must have been created
before.
MMEM:MDIR 'C:\Documents and
Settings\New_Directory\New_Subdirectory'
Create an additional subdirectory.
MMEM:CDIR 'C:'; MDIR 'New_Rootdirectory'
Create an additional directory C:\New Rootdirectory.
