R&S ZVB - Page 801

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 786
*RST value
–
SCPI,
Command
Types
Device-specific, no query.
Example:
*RST; :CALC:TRAN:VNET:PPA:EMB:DEF 1,2,3,4
Define a port pair configuration with two port pairs (<List_idx> = 1 or 2).
CALC:TRAN:VNET:PPA:EMB2:TND STSL
Select the Serial .s2p data, shunt L circuit mode for port
pair no. 2.
MMEM:LOAD:VNET:PPA:EMB2 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\Traces\Test.s2p', PMA
Load a Touchstone file and assign it to port pair no. 2.
MMEMory:LOAD:VNETworks<Ch>:SENDed:DEEMbedding<Ph_pt> '<file_name>'[,
IPORts]
Loads data from a specified two-port (*.s2p) Touchstone file defining a single ended circuit model for
deembedding. Select the single ended port circuit model involving file import (FIMPort)before using the
command.
<Ch>
Channel number.
<Ph_pt>
Physical port number
'<file_name>'
String parameter to specify the name and directory of the loaded Touchstone file.
If no path is specified the analyzer searches the current directory, to be queried
with MMEMory:CDIRectory?.
*RST value
–
[IPORts]
Interchange port numbers of loaded *.s2p file. If the parameter is omitted, the port
numbers are not interchanged.
SCPI,
Command
Types
Device-specific, no query.
Example:
CALC:TRAN:VNET:SEND:DEEM:TND FIMP
Select the Serial .s2p data circuit model.
MMEM:LOAD:VNET:SEND:DEEM2 'C:\Program
Files\Rohde&Schwarz\Network Analyzer\VNET\Test.s2p'
Load a Touchstone file and assign it to the physical port
no. 2.
