OUTPut<Ch>:UPORt:BUSY:LINK <BusyCoupledTo>
Defines the behavior of the BUSY output signal at pin no. 4 of the USER CONTROL connector on the rear
panel of the analyzer.
<Ch>
Channel number.
<BusyCoupledTo>
AUTO – Auto (according to the triggered measurement sequence)
POInt – Sweep point
PPOint – Partial measurement
SEGMent – Sweep segment
SWEep – Entire sweep
*RST value
AUTO
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; :TRIGger:SEQuence:LINK?; :OUTP:UPORt:BUSY:LINK?
Reset the analyzer and query the triggered measurement sequence. The
response is 'SWEEP';AUTO. The BUSY signal is turned on ("High" state)
when the analyzer acquires the fist partial measurement data of the first
sweep point. It returns to "Low" state after the last partial measurement of the
last sweep point has been acquired.
OUTPut<Ch>:UPORt:ECBits <Boolean>
Defines whether or not pins 16 to 19 of the USER CONTROL connector on the rear panel of the analyzer
shall be used as extra channel bits 4 to 7.
This setting will only take effect if lines 16 to 19 are not used as segment bits (see
OUTPut<Ch>:UPORt:SEGMent:STATe).
<Ch>
Channel number.
<Boolean>
ON – use them as extra channel bits
OFF – do not use them as extra channel bits
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
*RST; :OUTPut1:UPORt:ECBits?
Returns 0 (OFF).
:OUTP1:UPORt:ECBits ON
Enables extra channel bits 4 to 8 (pins 16 to 19).
OUTPut<Ch>:UPORt:SEGMent<Seg>:STATe <Boolean>
Enables or disables segment bits for the sweep segments in channel no. <Ch>; see
OUTPut<Ch>:UPORt:SEGMent<Seg>[:VALue]. The command is valid for segmented frequency
sweep.
