ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 844
2. As part of the calibration sequence a temporary channel is created, which must not be
modified by any means. This channel is deleted when the SAVE command is called, so
in order to finish the calibration procedure (complete or incomplete) always use the
SAVE command
3. Mixed operation GUI|remote is not supported
4. If several calibration units are connected via USB, use
SYSTem:COMMunicate:RDEVice:AKAL:ADDRess to select a particular one for the
calibration
<Ch>
Channel number
BASE | MIXer
BASE – One-port calibration with calibration unit
MIXer - Mixer calibration
<Dispersion>
boolean
Optional status parameter of the mixer:
 If FALSE (or omitted) the mixer is non-dispersive
 If TRUE the mixer is dispersive
AUTO | <delay |
phase>
The missing mixer parameter can either be calculated automatically (AUTO) or
specified by the user (<delay | phase>)
If not set to AUTO, the parameter is interpreted as
 delay(in picoseconds) if <Dispersion> is FALSE
 phase (in degrees) if <Dispersion> is TRUE
*RST value
–
SCPI, Command
Types
Device-specific, no query
Example:
CORR:COLL:AUTO:VMIX:ACQ BASE
CORR:COLL:AUTO:VMIX:ACQ MIX
CORR:COLL:AUTO:SAVE
or equivalently
CORR:COLL:AUTO:VMIX:ACQ MIX
CORR:COLL:AUTO:VMIX:ACQ BASE
CORR:COLL:AUTO:SAVE
[SENSe<Ch>:]CORRection:COLLect:CONNection<port_no> N50FEMALE |
N50MALE | N75FEMALE | N75MALE | PC35FEMALE | PC35MALE | PC7 |
PC292FEMALE | PC292MALE | PC24FEMALE | PC24MALE | PC185FEMALE |
PC185MALE | PC1FEMALE | PC1MALE | SMAFEMALE | SMAMALE
Additional parameters (): UFEMALE1 | UMALE1 | UFEMALE2 | UMALE2 | ...
Selects a connector type at a specified port <port_no> and its gender.
Use [SENSe<Ch>:]CORRection:COLLect:SCONnection<port_no> to select an arbitrary
connector type using a string variable.
