R&S ZVB - Page 860

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 845
<Ch>
Channel number
<port_no>
Port number of the analyzer.
Note: If the analyzer is set to use the same connectors at all ports
([SENSe<Ch>:]CORRection:COLLect:CONNection<port_no>:PORTs ALL),
then a change of a connector type is valid for all ports. The gender of the connectors
can still be different.
Parameters
Connector type and gender of the connectors (omitted for query). PC1MALE denotes
a 1.0 mm (m) connector, PC185MALE a 1.85 mm (m) connector and so forth.
UFEMALE<i> and UMALE<i> refer to the female and male form of the user-defined
connector type with default name UserConn<i>.
User-defined connector types must be defined before being addressed by
[SENSe<Ch>:]CORRection:COLLect:CONNection<port_no> or
[SENSe<Ch>:]CORRection:COLLect:SCONnection<port_no>.
*RST value
N50FEMALE for all ports.
SCPI,
Command
Types
Device-specific, command or query.
Example:
*RST; :CORR:COLL:CONN1 N75MALE; CONN4?
Change the connector type at port 1 from N50FEMALE to N75MALE. The connector
type at the other ports is also changed to N75, however, the gender (female) is
maintained. CORR:COLL:CONN4? returns N75FEMALE.
[SENSe<Ch>:]CORRection:COLLect:CONNection<port_no>:GENDers ALL |
SINGle
Qualifies whether the genders of the connectors at the analyzer ports (but not their types) are equal or
independent.
<Ch>
Channel number
<port_no>
Port number of the analyzer. This suffix is ignored; the command affects all ports.
Parameters
ALL: Equal (uniform) connector genders. If the gender at one port is changed, the
gender at all other ports is changed accordingly.
SINGle: Independent (possibly non-uniform) connector genders at the ports.
*RST value
SINGle
SCPI,
Command
Types
Device-specific, command or query.
Example:
See [SENSe<Ch>:]CORRection:COLLect:CONNection:PORTs.
[SENSe<Ch>:]CORRection:COLLect:CONNection<port_no>:PORTs ALL | SINGle
Qualifies whether the connector types at the analyzer ports (but not their genders) are equal or
independent. Some calibration types require uniform port connector types.
<Ch>
Channel number
