R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 846
Port number of the analyzer. This suffix is ignored; the command affects all ports.
ALL: Equal (uniform) connector types. If the connector type at one port is
changed, the connector type at all other ports is changed accordingly.
SINGle: Independent (possibly non-uniform) connector types at the ports.
Device-specific, command or query.
CORR:COLL:CONN:PORT SING; :CORR:COLL:CONN:GEND SING
Select independent connector types and genders at the ports.
CORR:COLL:CONN1 N50MALE; CONN4 N75FEMALE; CONN2?
Select independent connector types at ports 1 and 4. The connector type at port 2
is not changed; the query returns the original connector type (depending on the
analyzer model), e.g. N50FEMALE.
CORR:COLL:CSET ON
Select the calibration method where the same sweep setup is used for all
standards.
CORR:COLL:DET AVER
Select an average detector for the calibration, e.g. for a noise figure measurement.
[SENSe<Ch>:]CORRection:COLLect:CSETup <Boolean>
Selects the sweep setup for the calibration sweeps. This setting is valid for manual and automatic
calibration.
ON – same sweep setup for all standards (no preparation phase for each
standard)
OFF – individual sweep setups (is faster for some configurations)
Device-specific, command or query
See [SENSe<Ch>:]CORRection:COLLect:CONNection<port_no>:PORTs
[SENSe<Ch>:]CORRection:COLLect:DELete ['<cal_name>' | ALL]
Deletes system error correction data generated and stored previously.
Name of the calibration (string parameter) defined together with the calibration
type ([SENSe<Ch>:]CORRection:COLLect:METHod:DEFine).
ALL – The analyzer deletes all calibrations.
If nothing is specified the analyzer deletes the last system error correction stored
by means of [SENSe<Ch>:]CORRection:COLLect:SAVE:SELected.
