R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 851
Type (Add Calibration dialog)
FOPORT1 | FOPORT2 |
FOPORT12
Full One Port at port 1 | at port 2 | at port 1 and 2
Forward One Path Two Port (node port: port 1) | Reverse One Path Two Port (node port: port 2)
Refl Norm Open at port 1 | at port 2 | at ports 1 and 2
FRTRans | FTRans |
RTRans
Trans Norm - Bidirectional | Trans Norm - Forward | Trans Norm - Reverse
Two-port normalization at ports 1 and 2 (corresponds to a Trans Norm - Bidirectional in combination
with a Refl Norm Open at both ports)
[SENSe<Ch>:]CORRection:COLLect:METHod:DEFine '<cal_name>', REFL |
RSHort | FOPort | FRTRans | FTRans | RTRans | OPTPort | TOSM | TOM | TRM |
TRL | NMTRl | TNA | UOSM, <port_no>[,<port_no>][
,<port_no>][,<port_no>]
Defines a one-port, two-port, three-port or four-port calibration for channel <Ch> at arbitrary analyzer ports
and adds it to the channel's "selected calibrations". This is similar to the Add Calibration function of the
generic Calibration Wizard (Channel - Calibration - Start Cal - Other).
Multiple non-redundant calibrations can be defined and added to a channel's selected calibrations by
calling this command multiple times with identical <Ch> but different '<cal_name>' parameters. After a
MMEMory:LOAD:CORRection or MMEMory:LOAD:CORRection:MERGe the loaded calibrations become
the selected ones.
The query and subsequent SENS:CORR:COLL:ACQ:SEL and SENS:CORR:COLL:SAVE:SEL commands
refer to all currently selected calibrations.
Name of the calibration (string identifier). Serves as a reference e.g. to delete a
particular set of system correction data (using
[SENSe<Ch>:]CORRection:COLLect:DELete; see also
SENS:CORR:COLL:SAVE:SEL).
If a non-redundant calibration with the given name is already defined it is
overwritten by the command.
[A calibration is redundant if another selected calibration provides more complete
correction data.]
If there is already a redundant calibration the parameter <cal_name> is ignored and
the existing calibration is reused with its already existing name.
Calibration types; see list below.
UOSM is interpreted as a mixer vector calibration if vector mixer measurements are
active ([SENSe<Ch>:]FREQuency:CONVersion VMIXer).
Port numbers of the analyzer. For an n-port calibration type (n = 1 to 4), n port
numbers must be specified. If more than n numbers are defined, the spare numbers
(the last ones in the list) are ignored. Entering less than n numbers causes an error
message. For a one path two port calibration (OPTPort), the first port no. denotes
the node port (fully calibrated port).
Device-specific, command or query.
The query returns the types of the currently selected calibrations, suffixed by the
calibrated ports (e.g. RSH01 ,UOSM0204, ...; comma-separated list).
