R&S ZVB - Page 897

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 882
The frequency ranges for the different instrument models are listed below:
ZVA8
ZVA24
ZVA40
ZVA50
ZVA67
Start,
Stop
300 kHz to 8
GHz
10 MHz to 25 GHz
(the specified frequency range is 10 MHz to
24 GHz; see data sheet)
10 MHz to 40
GHz
10 MHz to 50
GHz
10 MHz to 67
GHz
Center
> 300 kHz to < 8
GHz
> 10 MHz to < 25 GHz
> 10 MHz to <
40 GHz
> 10 MHz to <
50 GHz
> 10 MHz to <
67 GHz
Span
10 mHz to
7.9997 GHz
10 mHz to 24.99 GHz
10 mHz to
39.99 GHz
10 mHz to
49.99 GHz
10 mHz to
66.99 GHz
Use SYSTem:FREQuency? MINimum | MAXimum. to query the frequency range of your analyzer.
Note: For a frequency sweep the range can be defined alternatively by a combination of Start/Stop
frequencies or a Center frequency and Span. In fixed frequency mode (power sweep or Time/CW Mode;
see [SENSe<Chn>:]FUNCtion[:ON]) the measurement frequency is set by means of
[SENSe<Ch>:]FREQuency:CW|FIXed.
[SENSe<Ch>:]FREQuency:CENTer <center_frequency>
Defines the center of the measurement and display range for a frequency sweep.
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
<center_frequency>
Center frequency of the sweep.
Range [def. unit]
Depending on the instrument model [Hz]. The increment (parameters UP or
DOWN) is 0.1 kHz.
*RST value
Center of the analyzer's maximum frequency range: (f
MIN
+ f
MAX
)/2
SCPI, Command
Types
Confirmed, command or query.
Example:
*RST; :SYST:FREQ? MIN; :SYST:FREQ? MAX
Activate a frequency sweep and query the frequency
range of the analyzer.
FREQ:CENT 100MHz
Set the center frequency to 100 MHz.
FREQ:SPAN 50000
Set the frequency span to 50 kHz.
The measurement range defined by means of the center frequency and the current span
([SENSe<Ch>:]FREQuency:SPAN) must not exceed the allowed frequency range of the analyzer. If
necessary, the span is reduced to min (Center – f
MIN
, f
MAX
– Center).
[SENSe<Ch>:]FREQuency:CONVersion FUNDamental | HARMonic | SHARmonic |
THARmonic | MIXer | VMIXer
Enables/disables a frequency converting measurement for channel <Ch>.
