R&S ZVB - Page 896

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 881
Types
Example:
EUN:PGEN:INP:EXT ON
Select an external pulse generator.
EUN:PGEN:ASS G2Mall
Use the pule generator signal 2 to control all three pulse modulators.
EUN:PGEN:OUTP:EXT ON
Select the EXT PULSE GENERATOR OUT connectors as output connectors
for the pulse generator signals.
[SENSe<Ch>:]EUNit:PGENerator:OUTPut:EXTernal <Boolean>
Routes either the R&S ZVA pulse generator signals or the external pulse generator signals to the PULSE
GENERATOR OUT connector.
<Ch>
Channel number
<Boolean>
ON – External pulse generator signals, fed in via EXT PULSE
GENERATOR IN
OFF – R&S ZVA signals, fed in via CASCADE IN
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]EUNit:PGENerator:INPut:EXTernal
[SENSe<Ch>:]EUNit:PMODulator<Path>[:STATe] <Boolean>
Loops pulse modulators into the RF signal paths no. <Path>. Paths no. 1 and 3 in the extension unit are
source paths, path no. 2 is a receiver path.
<Ch>
Channel number
<Path>
Signal path no. 1, 2, or 3. If unspecified, this parameter is set to 1.
<Boolean>
ON – Pulse modulator used
OFF – No pulse modulator (through path)
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]EUNit:COMBiner[:STATe]
[SENSe<Ch>:]FREQuency...
This subsystem sets frequency-related parameters, especially the measurement and display ranges for
the different sweep types, and controls the frequency-converting measurement modes (harmonic
distortion, mixer mode, etc.).
