R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 880
<Boolean>
ON – Harmonic filter used
OFF – No harmonic filter (through path)
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]EUNit:COMBiner[:STATe]
[SENSe<Ch>:]EUNit:LNAMplifier[:STATe] <Boolean>
Loops the low noise preamplifier into the RF receiver path no. 2. No path suffix is required.
<Ch>
Channel number
<Boolean>
ON – Low-noise amplifier used
OFF – No low-noise amplifier (through path)
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]EUNit:COMBiner[:STATe]
[SENSe<Ch>:]EUNit:PGENerator:ASSignment G1Mall | G2Mall | G1M2 | G1M3
Defines the assignment between pulse generator signals and pulse modulators.
<Ch>
Channel number
Parameters
G1Mall – Generator signal 1 controls all three modulators
G2Mall – Generator signal 2 controls all three modulators
G1M2 – Generator signal 1 controls modulators 1 and 2, generator signal 2
controls modulator 3
G1M3 – Generator signal 1 controls modulators 1 and 3, generator signal 2
controls modulator 2
*RST value
G1M
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]EUNit:PGENerator:INPut:EXTernal
[SENSe<Ch>:]EUNit:PGENerator:INPut:EXTernal <Boolean>
Selects the R&S ZVA or an external pulse generator as a source for the pulse generator signals.
<Ch>
Channel number
<Boolean>
ON – External generator signals, fed in via EXT PULSE GENERATOR IN
OFF – R&S ZVA signals, fed in via CASCADE IN
*RST value
OFF
SCPI, Command
Device-specific, command or query
