SCPI Command Reference
Operating Manual 1145.1084.12 – 30 879
Example:
COUP NONE
Activate the alternating sweep mode.
TRIG:LINK 'PPO'
Set the triggered measurement sequence equal to one partial measurement.
Each trigger event starts one partial measurement for all sweep points.
[SENSe<Ch>:]EUNit...
This subsystem configures the different signal paths in the Extension Unit R&S ZVAX24 and selects the
connectors for the pulse generators.
[SENSe<Ch>:]EUNit:COMBiner<Path>[:STATe] <Boolean>
Switches the internal combiner in-between the RF signal paths no. 1 and 3 (source path).
<Ch>
Channel number. If unspecified, this parameter is set to 1.
<Path>
Signal path, must be set to 1 (or omitted).
<Boolean>
ON – Internal combiner used. The combined source signals of the R&S ZVAX
signal paths 1 and 3 are available at the NWA port 1.
OFF – No combiner used (through path). The source signals of the R&S ZVAX
signal paths 1 and 3 are available at the NWA ports no. 1 and 3, respectively.
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
EUN:COMB ON
Activate the internal combiner.
EUN:HFIL1 ON; HFIL3 ON
Loop harmonic filters into the source signal paths no. 1 and 3.
EUN:PMOD1 ON; PMOD3 ON
Loop pulse modulators into the source signal paths no. 1 and 3.
EUN:LNAM ON
Loop the low-noise preamplifier into the receiver signal path no. 2.
[SENSe<Ch>:]EUNit:HFILter<Path>[:STATe] <Boolean>
Loops harmonic filters into the RF signal paths no. <Path>. Paths no. 1 and 3 in the extension unit are
source paths, path no. 2 is a receiver path.
<Ch>
Channel number
<Path>
Signal path no. 1, 2, or 3. If unspecified, this parameter is set to 1.
