R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 883
Enabling a (different) frequency converting measurement also resets the measured quantity; see
program example below.
Measurement of the fundamental signal (no frequency-converting mode).
When a frequency conversion is reset, the status of
SENSe<Ch>:FREQuency:CONVersion:AWReceiver[:STATe] is reset to 1 (= ON =
measure source port waves at receiver frequency).
Harmonics measurement. The order of the measured harmonic, the source port,
and the receive port must be selected using the
[SENSe<Ch>:]FREQuency:CONVersion:HARMonic... commands; see
example below.
Measurement of the 2nd or 3rd harmonic with source port 1 and receive port 2.
These parameters have been introduced for compatibilty with the ZVR. While they
are active, a query returns HARM.
Scalar or vector mixer mode. Both mixer modes are configured using the
[SENSe<Ch>:]FREQuency:CONVersion:MIXer... commands.
Device-specific, command or query. Returned values: FUND or HARM.
*RST; FREQ:STAR 0.5E+9; STOP 1E+9
Reset the analyzer (activating a frequency sweep) and set the sweep range
between 1 GHz and 1.1 GHz.
FREQ:CONV:HARM:ORD 4; SPOR 1; RPOR 2
Configure a 4th harmonic measurement with source port 1 and receive port 2. The
measurement is still not enabled.
FREQ:CONV HARM
Enable the configured harmonic measurement.
CALC:PAR:MEAS? "TRC1"
Query the measured quantity. The analyzer measures the wave quantity b2, the
response is 'B2D1SAM'.
FREQ:CONV:HARM:RELative ON
Enable the relative harmonic measurement, creating a new channel and a new
trace Trc2.
CALC2:PAR:MEAS? "TRC2"
Query the measured quantity in the new channel no. 2. The analyzer still measures
the wave quantity b2, the response is 'B2D1SAM'.
CALC2:MATH:STAT?
Check whether the active trace in channel no. 2 (i.e. Trc2) is a mathematical
trace: the response is 1.
