R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 900
*RST; FREQ:CONV:MIX:LOF 3 GHz
Reset the analyzer and specify a fixed frequency of 1 GHz, to be assigned to the
LO signal.
FREQ:STAR 1 GHz; STOP 2 GHz
Define a sweep range between 3 and 4 GHz, to be assigned to the RF signal.
FREQ:CONV:MIX:TFR DCL
Select down conversion to the lower sideband, corresponding to an IF frequency
range between 2 GHz and 1 GHz.
[SENSe<Ch>:]FREQuency...
This subsystem sets frequency-related parameters, especially the measurement and display ranges for
the different sweep types, and controls the harmonic distortion measurement.
Note: For a frequency sweep the range can be defined alternatively by a combination of Start/Stop
frequencies or a Center frequency and Span. In fixed frequency mode (power sweep or Time/CW Mode;
see [SENSe<Chn>:]FUNCtion[:ON]) the measurement frequency is set by means of
[SENSe<Ch>:]FREQuency:CW|FIXed.
[SENSe<Ch>:]FREQuency[:CW]|:FIXed <CW_frequency>
Defines the fixed (Continuous Wave, CW) frequency for all sweep types operating at fixed frequency
(power sweep, time sweep, CW mode sweep). The two command forms FREQ:CW and FREQ:FIX are
equivalent.
[SENSe<Ch>:]FREQuency:CW|FIXed is equivalent to
SOURce<Ch>:FREQuency<Pt>:CW|FIXed. Source and receiver frequency are equal; the four
commands overwrite each other. With option ZVA-K4, Frequency Conversion, independent offset
frequencies can be defined for the source and receiver frequencies; see
SOURce<Ch>:FREQuency<Pt>:CONVersion:ARBitrary:IFRequency and
[SENSe<Ch>:]FREQuency:CONVersion:ARBitrary.
Fixed stimulus and analyzer frequency.
Depending on the instrument model [Hz]. The increment (parameters UP or
DOWN) is 0.1 kHz.
Confirmed, command or query.
FUNC "XPOW:POW:A1"
Activate a power sweep and select the wave quantity a1 as measured
parameter for channel and trace no. 1.
FREQ:CW 100MHz
Set the CW frequency to 100 MHz.
