SCPI Command Reference
Operating Manual 1145.1084.12 – 30 899
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:RFPort <port_number>
Selects an analyzer port as source port for the RF signal.
For mixer delay measurements and vector mixer measurements (options R&S ZVA-K5, R&S ZVA-K9,
R&S ZVA-K10), the RF signal must be generated at port 1.
<Ch>
Channel number
<port_number>
Analyzer port number (physical port)
Range [def. unit]
1 to number of analyzer ports [1].
*RST value
1
SCPI, Command Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:STAGes <mixers>
Selects the number of converter/mixer stages for scalar mixer measurements and intermodulation
distortion measurements.
For mixer delay measurements and vector mixer measurements (options R&S ZVA-K5, R&S ZVA-K9,
R&S ZVA-K10), a single mixer stage is supported only.
<Ch>
Channel number
<mixers>
Range [def. unit]
1 | 2 [–]
*RST value
1
SCPI, Command Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:TFRequency<Stg> DCLower |
DCUPper | UCONversion | BAND1 | BAND2
Selects the frequency conversion modes of the IF signal.
<Ch>
Channel number
<Stg>
Mixer stage (1 or 2; see
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:STAGes)
DCLower
DCUPper
UCONversion
IF = LO – RF (down conversion lower sideband, equivalent to BAND1)
IF = RF – LO (down conversion upper sideband, equivalent to BAND2)
IF = LO + RF (up conversion)
*RST value
DCUPper
SCPI, Command
Types
Device-specific, command or query
