<denominator>
Range [def. unit]
1, 2, 3 ... [1]
*RST value
1
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:LOPort<Stg> NONE | EMBedded |
PORT, <port_number> | GENerator, <gen_number>
Selects an analyzer or an external generator port as a signal source for the LO 1 or LO 2 signal.
For mixer delay measurements and vector mixer measurements (options R&S ZVA-K5, R&S ZVA-K9,
R&S ZVA-K10), ports 1 and 2 are reserved for the RF and IF signals, respectively. Only a single mixer
stage (<Stg> = 1) is supported.
<Ch>
Channel number
<Stg>
Mixer stage (signals LO 1 or LO 2; see
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:STAGes)
NONE
LO signal is not controlled by the analyzer.
EMBedded
LO is embedded in the DUT, and not controlled by or synchronized with the
analyzer (see Define Scalar Mixer Meas).
PORT,
<port_number>
Analyzer port number
Range [def. unit]
1 to number of analyzer ports [1]
*RST value
NONE
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed RF | LO | LO1 | LO2 | IF,
<fixed_frequency>
Assigns a fixed frequency to the RF, LO 1, LO 2, or to the IF signal. The fixed frequency setting becomes
active if the port is selected as a port with fixed frequency
([SENSe<Ch>:]FREQuency:CONVersion:MIXer:FIXed<Stg>).
<Ch>
Channel number
Port parameters
RF – mixer input signal
LO | LO1 – local oscillator signal no. 1
LO2 – local oscillator signal no. 2, for 2-stage mixer measurements
([SENSe<Ch>:]FREQuency:CONVersion:MIXer:STAGes)
IF – mixer output signal
<fixed_frequency>
Fixed frequency for the specified port
Range [def. unit]
Depending on the instrument model [Hz]. The increment (parameters UP or
