ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 898
<Ch>
Channel number
<Boolean>
ON | OFF – enable or disable RF image measurement.
*RST value
OFF
SCPI, Command Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:RFFixed <fixed_frequency>
[Deprecated command, replaced by [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed]
Defines a fixed frequency and assigns it to the RF signal (for alternative commands see example below).
<Ch>
Channel number
<fixed_frequency>
Fixed frequency.
Range [def. unit]
Depending on the instrument model [Hz]. The increment (parameters UP or
DOWN) is 0.1 kHz.
*RST value
Minimum of the analyzer's frequency range, f
MIN
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; FREQ:CONV:MIX:RFF 1 GHz
Reset the analyzer and specify a fixed frequency of 1 GHz, to be assigned
to the RF signal.
FREQ:CONV:MIX:FFIX?; FIX?
Query the fixed frequency and the signal assignment using the alternative
commands. The response is 1000000000;RF.
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:RFMultiplier <numerator>,
<denominator>
Selects the frequency conversion factor for the RF signal.
The frequency conversion factors for vector mixer measurements (options R&S ZVA-K5) must be
equal to 1.
<Ch>
Channel number
<numerator>, <denominator>
The conversion factor is a ratio of two integer numbers
Range [def. unit]
1, 2, 3 ... [1]
*RST value
1
SCPI, Command Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed
