R&S ZVB - Page 862

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 847
*RST value
–
SCPI,
Command
Types
Device-specific, no query
Example:
CORR:COLL:METH:DEF 'Test',RSHort,1
Select a one-port normalization at port 1 with a short standard as calibration type.
CORR:COLL:SEL SHOR,1
Measure a short standard connected to port 1 and store the measurement results
of this standard.
CORR:COLL:SAVE:SEL
CORR:COLL:DEL
Calculate the system error correction data and apply it to the active channel, then
delete the data.
[SENSe<Ch>:]CORRection:COLLect:DETector NORMal | AVERage
Selects the S-parameter detector type during the calibration.
<Ch>
Channel number
Parameters
AVERage: AVG detector, especially for noise figure measurements
NORMal: Normal detector, recommended for all other applications
*RST value
NORMal
SCPI, Command Types
Device-specific, command or query.
Example:
See [SENSe<Ch>:]CORRection:COLLect:CONNection<port_no>:PORTs
[SENSe<Ch>:]CORRection:COLLect:FIXTure[:ACQuire] OPEN | SHORT,
<port_no>{,<port_no>}
Starts a fixture compensation sweep in order to acquire measurement data for a test fixture that has its
inner conductor terminated with the selected standards.
<Ch>
Channel number
OPEN, SHORt
Standard type, open or short circuit
<port_no>
Port numbers of the analyzer. For an n-port fixture compensation (n = 1 to 4), n
arbitrary (not necessarily consecutive) port numbers must be specified.
*RST value
–
SCPI,
Command
Types
Device-specific, no query
Example:
*RST; CORR:COLL:FIXT:LMP:LOSS OFF
Configure a fixture compensation measurement (for all channels): The analyzer
performs an Auto Length (no loss) calculation.
CORR:COLL:FIXT:ACQ OPEN, 2; :CORR:COLL:FIXT:ACQ SHOR, 4
