R&S ZVB - Page 863

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 848
Perform a fixture compensation sweep at port 2, terminated with an open
standard, and at port 4, terminated with a short.
CORR:COLL:FIXT:SAVE
Save and apply the compensation data.
CORR:COLL:FIXT:STAR
Prepare a new fixture compensation measurement, deleting the previous data for
channel 1.
CORR:COLL:FIXT:LMP OFF
Select a Direct Compensation measurement (for all channels and traces).
CORR:COLL:FIXT:ACQ SHOR, 1, 3
Perform a fixture compensation sweep at ports 1 and 3, terminated with a short
standard.
CALC2:PAR:SDEF 'Trc2', 'S22'
Create channel no. 2 with a trace named Trc2.
SENS2:CORR:COLL:FIXT:STAR
Prepare a fixture compensation measurement for channel 2. The channel 1 data
is not affected.
SENS2:CORR:COLL:FIXT:ACQ SHOR, 1, 3
Repeat the previous fixture compensation sweep for channel 2.
SENS1:CORR:COLL:FIXT:SAVE; :SENS2:CORR:COLL:FIXT:SAVE
Save and apply the compensation data for both channels.
SENS1:CORR:OFFS3:DFC?; :SENS2:CORR:OFFS3:DFC?
Query whether the analyzer uses Direct Compensation results at port 3. The
response is 1;1 (true for both channels).
[SENSe<Ch>:]CORRection:COLLect:FIXTure:LMParameter:LOSS[:STATe]
<Boolean>
Selects an Auto Length or an Auto Length and Loss calculation.
<Ch>
Channel number (ignored)
<Boolean>
1 – Auto Length and Loss
0 – Auto Length, no loss
*RST value
1
SCPI, Command Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]CORRection:COLLect:FIXTure[:ACQuire]
[SENSe<Ch>:]CORRection:COLLect:FIXTure:LMParameter[:STATe] <Boolean>
Selects an Auto Length (and Loss) calculation or a Direct Compensation.
