R&S ZVB - Page 868

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 853
[SENSe<Ch>:]CORRection:COLLect:NFIGure:END
Terminates a noise figure calibration, discarding the acquired data (see note for
[SENSe<Ch>:]CORRection:COLLect:NFIGure[:ACQuire]).
<Ch>
Channel number
SCPI, Command Types
Device-specific, no query
Example:
See Noise Figure Measurement (condensed programming examples)
[SENSe<Ch>:]CORRection:COLLect:NFIGure:SAVE
Completes a noise figure calibration, storing and applying the acquired data (see note for
[SENSe<Ch>:]CORRection:COLLect:NFIGure[:ACQuire]).
<Ch>
Channel number
SCPI, Command Types
Device-specific, no query
Example:
See Noise Figure Measurement (condensed programming examples)
[SENSe<Ch>:]CORRection:COLLect:NFIGure:STARt <port1_no>, <port2_no>,
<ext_att_ON | OFF>, <src_ncal_att>, <DUT_meas_att>
Defines the calibration settings (port assignment, attenuations) for a noise figure calibration.
<Ch>
Channel number
<port1_no>,
<port2_no>,
Port numbers of the DUT output (<port1_no>) and the DUT input. The port
numbers may be different from each other or equal.
<ext_att_ON | OFF>,
ON | OFF – Boolean parameter, indicates whether an external attenuator is
used.
<src_ncal_att>,
Attenuation of the source level during the source noise calibration.
<DUT_meas_att>
Attenuation of the source level during the measurement (i.e. after
calibration).
*RST value
–
SCPI, Command
Types
Device-specific, no query
Example:
See Noise Figure Measurement (condensed programming examples)
[SENSe<Ch>:]CORRection:COLLect:RPSHift <value>[, <cal_name>]
Specifies the reference plane shift to be applied to the result of a NIST Multiline TRL calibration. The
<value> is entered as a mechanical length, where positive values denote a transformation towards the
DUT, and negative values towards the connector. The default is 0 and corresponds to a reference plane at
the connector plane. If the optional <cal_name> parameter is missing the reference plane shift is applied
to all existing NIST Multiline TRL calibrations on channel <Ch>. If the optional <cal_name> parameter is
