R&S ZVB - Page 901

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 886
<Boolean>
OFF - Measurement at source frequency
ON - Measurement at receiver frequency
*RST value
ON
SCPI, Command Types
Device-specific, command or query.
Example:
FREQ:CONV:AWR ON
Measure a waves at the receiver frequency.
[SENSe<Ch>:]FREQuency:CONVersion:DEVice:MODE RILI | RILE | RILI4 | RILI56
Selects the test setup (internal or external sources) for the frequency converter measurement (with option
ZVA-K8, Converter Control).
The available test setups depend on the instrument type:
RILI
RILE
RILI4
RILI56
R&S ZVA 24|40|50
x
x
R&S ZVA 67
x
x
R&S ZVT 20
x
x
This is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
RILI
RF internal, LO internal (4-Port)
Ports 1 and 2: Converter RF Signal
Ports 3 and 4: Converter LO
RILE
RF internal, LO external (4-Port)
Ports 1 to 4: Converter RF Signal
External Generator #1: Converter LO
RILI4
RF internal, LO internal, Port4=LO (R&S ZVA 67 only)
Ports 1 and 2: Converter RF Signal
Port 4: Converter LO
RILI56
RF internal, LO internal, 6-Port (R&S ZVT 20 only)
Ports 1 to 4: Converter RF Signal
Ports 5 and 6: Converter LO
*RST value
RILI
SCPI, Command
Types
Device-specific, command or query.
Example:
FREQ:CONV:DEV:NAME 'ZVA-Z110'
