R&S ZVB - Page 902

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 887
Select frequency converter type R&S ZVA-Z110.
SYST:COMM:RDEV:GEN1:DEF 'Ext. Gen. 1', 'SME02', 'gpib0', '21'
Configure an R&S SME02 generator as external generator no. 1, assigning the
name Ext. Gen. 1 and a GPIB address 21.
FREQ:CONV:DEV:MODE RILE
Measure a waves at the receiver frequency.
[SENSe<Ch>:]FREQuency:CONVersion:DEVice:NAME '<Converter Type>'
Selects the frequency converter type for enhanced frequency-converting measurements (with option ZVA-
K8, Converter Control). The preset configuration will be reset to Instrument scope
(SYSTem:PRESet:SCOPe ALL) and Factory Preset (SYSTem:PRESet:USER:STATe OFF).
This is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
'<Converter Type>'
'ZVA-Z110' - Frequency converter R&S ZVA-Z110
'' - No frequency converter selected
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
Example:
See [SENSe<Ch>:]FREQuency:CONVersion:DEVice:MODE
[SENSe<Ch>:]FREQuency:CONVersion:DEVice:PCOefficient<Port> <C0>, <C1>,
<C2>, <C3>
Defines power coefficients for frequency converters R&S ZVA-ZxxxE.
This is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
<Port>
NWA port number
<C0>, <C1>,
<C2>, C3>
Coefficient of order 0, 1, 2, and 3.
Range [def.
unit]
-500 to +500 [–].
*RST value
Depending on the individual converter
SCPI,
Command
Types
Device-specific, command or query.
Example:
See
[SENSe<Ch>:]FREQuency:CONVersion:DEVice:PCOefficient:DEFault
