[SENSe<Ch>:]FREQuency:CONVersion:DEVice:PCOefficient<Port>:DEFault
<Boolean>
Enables or disables default power coefficients for frequency converters R&S ZVA-ZxxxE.
This is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
<Port>
NWA port number. This suffix is ignored because the command affects all ports.
<Boolean>
ON - Use default power coefficients
OFF - Use power coefficients defined via
[SENSe<Ch>:]FREQuency:CONVersion:DEVice:PCOefficient<Port>
*RST value
ON
SCPI,
Command
Types
Device-specific, command or query.
Example:
FREQ:CONV:DEV:NAME 'ZVA-Z110E'
Select frequency converter type R&S ZVA-Z110E.
FREQ:CONV:DEV:PCO3:DEF OFF
FREQ:CONV:DEV:PCO3 0.5479,0.03426,-0.002866,2.124E-006
Re-define the power coefficients for port 3 according to the connected converter unit.
FREQ:CONV:DEV:PCO3:DEF ON
Use default power coefficients for all ports.
FREQ:CONV:DEV:PCO3?
Query the default power coefficients for port 3. The analyzer returns the predefined
values (generally different from the coefficients entered above).
[SENSe<Ch>:]FREQuency:CONVersion:GAIN:LMCorrection <Boolean>
Enables the load match correction for frequency conversion measurements. The load match correction
requires an enabled Enhanced Wave Correction ([SENSe<Ch>:]CORRection:EWAVe[:STATe] ON).
<Ch>
Channel number.
<Boolean>
ON | OFF - Enable or disable load match correction
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
Example:
SENSe1:CORRection:EWAVe:STATe ON
Activate enhanced wave correction for channel 1.
SENSe1:FREQuency:CONVersion:GAIN:LMCorrection ON
Activate load match correction for frequency conversion measurements.
