R&S ZVB - Page 881

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 866
<port_no>
Port number of the analyzer
<length>
Electrical length
Range [def.
unit]
–1E+9 m to +1E+9 m [m]. The increment (UP, DOWN) is 1 mm.
*RST value
0 m
SCPI,
Command
Types
Device-specific, command or query
Example:
CORR:EDEL2:ELEN 0.3
Define an electrical length of 30 cm for channel 1 and port no. 2.
CORR:EDEL2:DIST?; DIEL?
Query the values of the mechanical length and the permittivity at port 2. The
mechanical length is equal to the electrical length divided by the square root of the
permittivity; the latter is set to its default value. The response is
0.29990704322;1.00062.
CORR:EDEL2?
Query the value of the delay at port 2. The delay is equal to the electrical length
divided by the speed of light in the vacuum, so the response is 1.0006922856E-009.
CORR:LOSS2 2; LOSS2:FREQ 1.5 GHz; OFFS 3 dB
Define the offset loss parameters at port 2.
[SENSe<Ch>:]CORRection:EDELay<port_no>[:TIME] <delay>
Defines the offset parameter for test port <port_no> as a delay time.
<Ch>
Channel number of the offset-corrected channel
<port_no>
Port number of the analyzer
<delay>
Delay
Range [def. unit]
-3.40282346638529E+038 s to +3.40282346638529E+038 s [s].
*RST value
0 s
SCPI, Command Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]CORRection:EDELay<port_no>:ELENgth
[SENSe<Ch>:]CORRection:EWAVe[:STATe] <Boolean>
Activates or deactivates the system error correction of all a- and b-waves which are related to the ports of
the active calibration.
<Ch>
Number of the active channel
<Boolean>
Enable or disable enhanced wave calibration
*RST value
OFF
