R&S ZVB - Page 906

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 891
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:LOFixed)
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:RFMultiplier
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:RFPort
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:STAGes
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:TFRequency<Stg>
 SOURce<Ch>:FREQuency<Pt>:CONVersion:MIXer:PMFixed
(replaces SOURce<Ch>:FREQuency<Pt>:CONVersion:MIXer:PFIXed and
SOURce<Ch>:FREQuency<Pt>:CONVersion:MIXer:PAFixed)
 SOURce<Ch>:FREQuency<Pt>:CONVersion:MIXer:PMODe
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:AEXTernal NONE | <gen_number>
Selects an external generator as a signal source for the Aux LO signal in a vector mixer measurement
(option R&S ZVA-K5). The Aux LO signal is fed to the MEAS and REF mixers.
<Ch>
Channel number
NONE
LO signal is not controlled by the analyzer.
<gen_number>
Number of external generator as defined in the System Configuration –
External Generators dialog.
*RST value
NONE
SCPI, Command
Types
Device-specific, command or query
Example:
See SOURce<Ch>:FREQuency:CONVersion:MIXer:PAFixed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:AINTernal NONE | <port_number>
Selects an analyzer port as a signal source for the Aux LO signal in a vector mixer measurement (option
R&S ZVA-K5). The Aux LO signal is fed to the MEAS and REF mixers.
<Ch>
Channel number
NONE
LO signal is not controlled by the analyzer.
<port_number>
Analyzer port number
Range [def. unit]
3 (for 3-port analyzers), 3, 4 (for 4-port analyzers)
No internal source is available for 2-port instruments.
*RST value
NONE
SCPI, Command Types
Device-specific, command or query
Example:
See SOURce<Ch>:FREQuency:CONVersion:MIXer:PAFixed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:APORt <port_number>
Selects the Aux Mixer port (and thus the basic test setup) for vector mixer measurements (option R&S
ZVA-K5).
