ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 890
[SENSe<Ch>:]FREQuency:CONVersion:HARMonic:SPORt <port_no> | <ext. gen.
no.>
Selects the source port for the harmonic measurement.
<Ch>
Channel number.
<port_no>
Positive integer analyzer port number.
<ext. gen. no.>
Negative integer external generator number (the minus sign serves as an identifier
for external generators; –1 denotes the external generator no. 1)
Range [def.
unit]
Depending on the analyzer model and the number of external generators [–].
*RST value
1
SCPI,
Command
Types
Device-specific, command or query.
Example:
See [SENSe<Ch>:]FREQuency:CONVersion
[SENSe<Ch>:]FREQuency:CONVersion:MIXer...
This subsystem controls the analyzer's mixer measurement mode. Together with the Harmonic Distortion
measurement, the intermodulation measurement, and the arbitrary configuration of generator and receiver
frequencies (Port Configuration), the mixer mode is included in option R&S ZVA-K4.
Deprecated and generalized mixer commands
With firmware version V2.90, the mixer measurement has been extended to support a second
mixer stage and frequency converters in the RF and LO signal paths. To account for these
changes, a new set of mixer commands has been introduced. The old mixer commands (marked
as deprecated commands in this documentation) are still supported, however, it is recommended
to use the new command set listed below.
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:AEXTernal NONE
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:AINTernal NONE
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:APORt
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:FIXed<Sig>
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:FUNDamental
(replaces SOURce<Ch>:FREQuency<Pt>:CONVersion:MIXer:FUNDamental)
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:IFPort
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:LOMultiplier<Stg>
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:LOPort<Stg>
(replaces [SENSe<Ch>:]FREQuency:CONVersion:MIXer:LOEXternal and
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:LOINternal)
 [SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed
(replaces [SENSe<Ch>:]FREQuency:CONVersion:MIXer:FFIXed,
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:RFFixed,
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:IFFixed, and
