ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 922
generator signal.
This suffix must be set to 1, the chopped pulse profile mode is general.
<Boolean>
ON | OFF – Enable or disable chopped pulse profile settings
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
PULS:GEN:DINC?
Query the delay increment.The response is 0 since chopped pulse profile
mode is not active.
PULS:GEN:CPPR ON; :PULS:GEN:DINC?
Enable chopped pulse profile settings. The delay increment is set to 200 ns.
PULS:GEN:DINC 0 ns
Define a zero delay increment. This disables the chopped pulse profile
mode.
[SENSe<Ch>:]PULSe:GENerator<gen_no>:DELay <Delay>
Defines the delay of the sync signal relative to the pulse generator signal.
<Ch>
Channel number.
<gen_no>
Number of the pulse generator signal. This suffix must be set to 1, the setting
is general.
<Delay>
Delay (to sync)
Range [def. unit]
-26.8435455875 s to +53.6870911875 s [s]. UP and DOWN
increment/decrement the delay in 12.5 ns steps.
*RST value
0 s
SCPI, Command
Types
Device-specific, command or query
Example:
Configure the pulse generator signal (<gen_no> = 1, omitted in commands).
PULS:GEN:DEL 100 ns
Define a 100 ns delay.
PULS:GEN:MODE CONT
Select continuous pulse mode.
PULS:GEN:MCH 1
Select channel 1 as master for continuous pulse mode.
PULS:GEN:PER 200 us
Select a pulse period of 200 μs.
PULS:GEN ON
Turn the pulse generator signals on.
