R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 930
Select pulse profile mode and activate coupled section limits.
SENS2:PULS:REC:A1:SRCP1:EVAL:STAR 200 ns
Create channel 2 and define a start value of 200 ns for the averaging section for
the a
1
receiver and source port no. 1.
SENS1:PULS:REC:A1:SRCP1:EVAL:STAR?
Query the section start value for channel 1. As the sections are coupled, the
response is 2E-007.
[SENSe<Ch>:]PULSe:RECeiver:A<rec_no>:GENerator<gen_no>:EVALuation:MOD
E NORMal | MEAN
Specifies whether the wave quantity assigned to the reference receiver <rec_no> and the external
generator <gen_no> is displayed as measured or whether it is averaged.
<Ch>
Channel number
<rec_no>
Number of the reference receiver (= port number of the analyzer). Values range
from 1 to the total number of test ports.
<gen_no>
Number of a previously configured external generator
Parameters
NORMal – wave quantity is as measured (pulse shape)
MEAN – wave quantity is replaced by its mean value (magnitude and phase)
averaged over a configurable time interval; see example below
*RST value
NORMal
SCPI, Command
Types
Device-specific, command or query
Example:
SYST:COMM:RDEV:GEN1:DEF 'Ext. Gen. 1', 'SME02', 'gpib0', '21'
Configure an R&S SME02 generator as external generator no. 1, assigning the
name Ext. Gen. 1 and a GPIB address 21.
PULS:REC:A2:GEN1:EVAL:STAR 200 ns; STOP 500 ns
Specify the averaging section for the a
2
receiver and the configured generator:
Define a start value of 200 ns and a stop value of 500 ns.
PULS:REC:A2:GEN1:LIN ON
Display the section limit lines in the diagram.
PULS:REC:A2:GEN1:EVAL:MODE MEAN
Enable averaging of the a
2
wave.
PULS:REC:A2:GEN1:TRIG:DEL 100 ns
Shift the stimulus axis of the a
2
wave by 100 ns.
