R&S ZVB - Page 944

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 929
*RST value
SINGle (for both signals)
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:GENerator<gen_no>:TRAin:DATA
[SENSe<Ch>:]PULSe:GENerator<gen_no>:WIDTh <Width>
Defines the pulse width of the pulse generator signal <gen_no>.
<Ch>
Channel number.
<gen_no>
Number of the pulse generator signal: 1 for pulse generator, 2 for sync
generator signal.
<Width>
Pulse width
Range [def. unit]
12.5 ns to 54948 s [s] for pulse generator signal, increment: 100 ns
12.5 ns to 53.6870911875 s [s] for sync signal, increment: 12.5 ns
*RST value
1 µs (for pulse generator signal)
200 ns (for sync signal)
SCPI, Command
Types
Device-specific, command or query
Example:
SENS1:PULS:GEN2:TYPE SING
Define a single pulse sync signal.
SENS1:PULS:GEN2:WIDT 100 ns
Define a pulse width of 100 ns for the sync signal.
SENS1:PULS:GEN2:POL INV
Invert the polarity of the sync signal.
[SENSe<Ch>:]PULSe...
This subsystem controls pulsed measurements (with option ZVA-K7, Measurements on Pulsed Signals).
[SENSe<Ch>:]PULSe:COUPled[:STATe] <Boolean>
Couples the section limits for averaging (and the section limit lines) for all receivers and source ports and
in all channels.
<Ch>
Channel number. If unassigned this value is set to 1.
<Boolean>
ON | OFF - Section limits coupled or uncoupled
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
*RST; SWE:TYPE PULS; :PULS:COUP ON
