[SENSe<Ch>:]PULSe:GENerator<gen_no>[:STATe] <Boolean>
Turns the pulse generator on or off.
<Ch>
Channel number.
<gen_no>
Number of the pulse generator signal. This parameter is ignored, the setting
affects both signals.
<Boolean>
ON | OFF – Turn pulse generator on or off
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:GENerator<gen_no>:DELay
[SENSe<Ch>:]PULSe:GENerator<gen_no>:TRAin:DATA <Active>, <Start High>,
<Stop High>{, <Active>, <Start High>, <Stop High>}
Adds and enables/disables an arbitrary number of pulse train segments. Each segment consists of a
single pulse of definite width and position which may be active or inactive.
This command does not overwrite existing pulse train segments. The defined segments are appended
to the list as new segments.
<Ch>
Channel number
<gen_no>
Number of the pulse generator signal. This suffix must be set to 1, since pulse trains
are available for the pulse generator signal only.
<Active>
Identifier for the state of the pulse train segment. The state of individual segments may
be changed using
[SENSe<Ch>:]PULSe:GENerator<gen_no>:TRAin:SEGMent<Seg>[:STATe]
Range
0 – Pulse train segment inactive, range defined but no pulse generated.
1 – Pulse train segment active
*RST value
1 (for all segments)
<Start
High>
Start time of the segment (pulse).
Range
[def. unit]
0 s to 54975.5813622 s [s]
*RST value
0 s (no pulse train segment defined after *RST)
<Stop
High>
Stop time of the segment (pulse).
Range
[def. unit]
12.5 ns to 54975.5813632 s [s]. The minimum width of a pulse is 12.5 ns, its maximum
width is given by the pulse train period
([SENSe<Ch>:]PULSe:GENerator<gen_no>:TRAin:PERiod).
*RST value
12.5 ns (no pulse train segment defined after *RST)
SCPI,
Command
Types
Device-specific, with query.
Example:
SENS1:PULS:GEN:TYPE TRA
Select a pulse train for the pulse generator signal.
