R&S ZVB - Page 941

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 926
SENS1:PULS:GEN:TRA:PER 1 us
Define a pulse train period of 1000 ns.
SENS1:PULS:GEN:TRA:DATA DEF, DEF, DEF, 0, 2.5E-8, 5E-8
Define and enable a pulse train segment with an active pulse between 0 s and 12.5 ns.
Define and enable a second active pulse train segment with an inactive pulse between
25 ns and 50 ns.
PULS:GEN:TRA:SEGM:COUN?
Display the number of defined segments. The response is 1.
PULS:GEN:TRA:SEGM2 ON
Set the second segment active.
PULS:GEN:TRA:SEGM2:STOP 200 ns; STAR 100 ns
Change position and length of second pulse.
PULS:GEN:TRA:DEL:ALL
Delete all pulse train segments
PULS:GEN:TRA:DATA?
Query existing pulse train segments. An error message "-114 "Header suffix out of
range..." indicates that there are no segments.
[SENSe<Ch>:]PULSe:GENerator<gen_no>:TRAin:DELete:ALL
Deletes all pulse train segments.
<Ch>
Channel number
<gen_no>
Number of the pulse generator signal. This suffix must be set to 1, since the
command affects the pulse generator signal only.
*RST value
–
SCPI,
Command
Types
Device-specific, no query.
Example:
See [SENSe<Ch>:]PULSe:GENerator<gen_no>:TRAin:DATA
[SENSe<Ch>:]PULSe:GENerator<gen_no>:TRAin:PERiod <Period>
Defines the pulse period of the pulse generator signal.
<Ch>
Channel number.
<gen_no>
Number of the pulse generator signal. This suffix must be set to 1; the period of the
sync signal is always adjusted to the pulse generator signal.
<Period>
Pulse period
Range [def.
unit]
12.5 ns to 54948 s [s]. UP and DOWN increment/decrement the delay in 1 μs
steps.
*RST value
100 μs
