R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 924
Parameters
CSPecific – Channel-specific pulse generator settings
CONTinuous – The settings of the master channel (set via
[SENSe<Ch>:]PULSe:GENerator<gen_no>:MCHannel <Channel>) are used
for all channels; continuous pulse generator signal on a channel change
*RST value
CSPecific
SCPI,
Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:GENerator<gen_no>:DELay
[SENSe<Ch>:]PULSe:GENerator<gen_no>:PERiod <Period>
Defines the pulse period of the single pulse generator signal
([SENSe<Ch>:]PULSe:GENerator<gen_no>:TYPE SINGle).
<Ch>
Channel number.
<gen_no>
Number of the pulse generator signal. This suffix must be set to 1; the period of
the sync signal is always adjusted to the pulse generator signal.
<Period>
Pulse period
Range [def. unit]
12.5 ns to 54948 s [s]. UP and DOWN increment/decrement the period in 1 μs
steps.
*RST value
10 μs
SCPI,
Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:GENerator<gen_no>:DELay
[SENSe<Ch>:]PULSe:GENerator<gen_no>:POLarity NORMal | INVerted
Selects the polarity of the pulse generator signal <gen_no>.
<Ch>
Channel number.
<gen_no>
Number of the pulse generator signal: 1 for pulse generator, 2 for sync
generator signal.
Parameters
NORMal – Normal polarity, high pulses
INVerted – Inverted polarity
*RST value
NORMal
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:GENerator<gen_no>:WIDTh
