ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 934
of the averaging section must be between 25 ns and 3 s.
*RST value
0 s
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:RECeiver:A<rec_no>:SRCPort<gen_no>:EVALuation:MODE
[SENSe<Ch>:]PULSe:RECeiver:A<rec_no>:SRCPort<port_no>:LINes[:STATe]
<Boolean>
Displays or hides the limit lines of the averaging section for the wave quantity assigned to the reference
receiver <rec_no> and the analyzer source port <port_no>.
<Ch>
Channel number
<rec_no>
Number of the reference receiver (= port number of the analyzer). Values range
from 1 to the total number of test ports.
<port_no>
Number of the analyzer source port. 1 to the total number of test ports.
<Boolean>
ON | OFF – Display or hide lines
*RST value
OFF
SCPI,
Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:RECeiver:A<rec_no>:SRCPort<gen_no>:EVALuation:MODE
[SENSe<Ch>:]PULSe:RECeiver:A<rec_no>:SRCPort<port_no>:TRIGger:DELay
<shift_stimulus>
Defines an offset time (shift stimulus) for the wave quantity assigned to the reference receiver <rec_no>
and the analyzer source port <port_no>.
<Ch>
Channel number
<rec_no>
Number of the reference receiver (= port number of the analyzer). Values range
from 1 to the total number of test ports.
<port_no>
Number of the analyzer source port. 1 to the total number of test ports.
<shift_stimulus>
Offset time
Range [def. unit]
–0.003 s to +0.003 s [s]. The increment (UP/DOWN) is 50 ns.
*RST value
0 s
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:RECeiver:A<rec_no>:SRCPort<gen_no>:EVALuation:MODE
[SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:GENerator<gen_no>:EVALuation:MOD
