ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 935
E NORMal | MEAN
Specifies whether the wave quantity assigned to the measurement receiver <rec_no> and the external
generator <gen_no> is displayed as measured or whether it is averaged.
<Ch>
Channel number
<rec_no>
Number of the measurement receiver (= port number of the analyzer). Values
range from 1 to the total number of test ports.
<gen_no>
Number of a previously configured external generator
Parameters
NORMal – wave quantity is as measured (pulse shape)
MEAN – wave quantity is replaced by its mean value (magnitude and phase)
averaged over a configurable time interval; see example below
*RST value
NORMal
SCPI, Command
Types
Device-specific, command or query
Example:
SYST:COMM:RDEV:GEN1:DEF 'Ext. Gen. 1', 'SME02', 'gpib0', '21'
Configure an R&S SME02 generator as external generator no. 1, assigning the
name Ext. Gen. 1 and a GPIB address 21.
PULS:REC:B2:GEN1:EVAL:STAR 200 ns; STOP 500 ns
Specify the averaging section for the b
2
receiver and the configured generator:
Define a start value of 200 ns and a stop value of 500 ns.
PULS:REC:B2:GEN1:LIN ON
Display the section limit lines in the diagram.
PULS:REC:B2:GEN1:EVAL:MODE MEAN
Enable averaging of the b
2
wave.
PULS:REC:B2:GEN1:TRIG:DEL 100 ns
Shift the stimulus axis of the b
2
wave by 100 ns.
[SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:GENerator<gen_no>:EVALuation:STA
Rt <section_start>
Defines the start time of the averaging section for the wave quantity assigned to the measurement
receiver <rec_no> and the external generator <gen_no>.
<Ch>
Channel number
<rec_no>
Number of the measurement receiver (= port number of the analyzer). Values
range from 1 to the total number of test ports.
<gen_no>
Number of a previously configured external generator
<section_start>
Start time of the section
Range [def. unit]
–0.003 s to +0.002999975 s [s]. The increment (UP/DOWN) is 50 ns. The width
of the averaging section must be between 25 ns and 3 s.
*RST value
0 s
SCPI, Command
Device-specific, command or query
