R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 936
Types
Example:
See [SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:GENerator<gen_no>:EVALuation:MODE
[SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:GENerator<gen_no>:EVALuation:STO
P <section_stop>
Defines the stop time of the averaging section for the wave quantity assigned to the measurement
receiver <rec_no> and the external generator <gen_no>.
<Ch>
Channel number
<rec_no>
Number of the measurement receiver (= port number of the analyzer). Values
range from 1 to the total number of test ports.
<gen_no>
Number of a previously configured external generator
<section_stop>
Stop time of the section
Range [def. unit]
–0.002999975 s to +0.003 s [s]. The increment (UP/DOWN) is 50 ns. The width
of the averaging section must be between 25 ns and 3 s.
*RST value
0 s
SCPI, Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:GENerator<gen_no>:EVALuation:MODE
[SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:GENerator<gen_no>:LINes[:STATe]
<Boolean>
Displays or hides the limit lines of the averaging section for the wave quantity assigned to the
measurement receiver <rec_no> and the external generator <gen_no>.
<Ch>
Channel number
<rec_no>
Number of the measurement receiver (= port number of the analyzer). Values range
from 1 to the total number of test ports.
<gen_no>
Number of a previously configured external generator
<Boolean>
ON | OFF – Display or hide lines
*RST value
OFF
SCPI,
Command
Types
Device-specific, command or query
Example:
See [SENSe<Ch>:]PULSe:RECeiver:B<rec_no>:GENerator<gen_no>:EVALuation:MODE
